• If you specify the "Authentication and High Level Encryption" security level in encryption key auto
exchange settings, also select the "Master key perfect forward secrecy (PFS)" check box in the Security
Filter Properties screen (which appears in step 29). If using PFS in Windows XP, the PFS group number
used in phase 2 is automatically negotiated in phase 1 from the Diffie-Hellman group number (set in
step 11). Consequently, if you change the security level specified automatic settings on the machine
and "User Setting" appears, you must set the same the group number for "Phase 1 Diffie-Hellman
Group" and "Phase 2 PFS" on the machine to establish IPsec transmission.
Encryption Key Manual Settings Configuration Flow
This section explains the procedure for specifying encryption key manual settings. This can be specified by
the network administrator.
• Before transmission, SA information is shared and specified by the sender and receiver. To prevent
SA information leakage, we recommend that this exchange is not performed over the network.
• After configuring IPsec, you can use "Ping" command to check if the connection is established correctly.
However, you cannot use "Ping" command when ICMP is excluded from IPsec transmission. Also,
because the response is slow during initial key exchange, it may take some time to confirm that
transmission has been established.
Specifying Encryption Key Manual Settings
This can be specified using Web Image Monitor.
Transmission Using IPsec
