Display current settings
msh> ipsec manual {1|2|3|4|default}
• To display the settings 1-4, specify the number [1-4].
• To display the default setting, specify [default].
• Not specifying any value displays all of the settings.
Disable settings
msh> ipsec manual {1|2|3|4|default} disable
• To disable the settings 1-4, specify the setting number [1-4].
• To disable the default settings, specify [default].
Specify the local/remote address for settings 1-4
msh> ipsec manual {1|2|3|4} {ipv4|ipv6} local address remote address
• Enter the separate setting number [1-4] or [default] and specify the local address and remote
address.
• To specify the local or remote address value, specify masklen by entering [/] and an integer
0-32 if you are specifying an IPv4 address. If you are specifying an IPv6 address, specify masklen
by entering [/] and an integer 0-128.
• Not specifying an address value displays the current setting.
Specify the address type in default setting
msh> ipsec manual default {ipv4|ipv6|any}
• Specify the address type for the default setting.
• To specify both IPv4 and IPv6, enter [any].
Security protocol setting
msh> ipsec manual {1|2|3|4|default} proto {ah|esp|dual}
• Enter the separate setting number [1-4] or [default] and specify the security protocol.
• To specify AH, enter [ah]. To specify ESP, enter [esp]. To specify AH and ESP, enter [dual].
• Not specifying a protocol displays the current setting.
SPI value setting
msh> ipsec manual {1|2|3|4|default} spi SPI input value SPI output value
• Enter the separate setting number [1-4] or [default] and specify the SPI input and output values.
• Specify a decimal number between 256-4095, for both the SPI input and output values.
Encapsulation mode setting
msh> ipsec manual {1|2|3|4|default} mode {transport|tunnel}
• Enter the separate setting number [1-4] or [default] and specify the encapsulation mode.
• To specify transport mode, enter [transport]. To specify tunnel mode, enter [tunnel].
7. Enhanced Network Security
200
7
