Display current settings
msh> ipsec ike {1|2|3|4|default}
• To display the settings 1-4, specify the number [1-4].
• To display the default setting, specify [default].
• Not specifying any value displays all of the settings.
Disable settings
msh> ipsec manual {1|2|3|4|default} disable
• To disable the settings 1-4, specify the number [1-4].
• To disable the default settings, specify [default].
Specify the local/remote address for settings 1-4
msh> ipsec manual {1|2|3|4} {ipv4|ipv6} local address remote address
• Enter the separate setting number [1-4], and the address type to specify local and remote
address.
• To set the local or remote address values, specify masklen by entering [/] and an integer 0-32
when settings an IPv4 address. When setting an IPv6 address, specify masklen by entering [/]
and an integer 0-128.
• Not specifying an address value displays the current setting.
Specify the address type in default setting
msh> ipsec manual default {ipv4|ipv6|any}
• Specify the address type for the default setting.
• To specify both ipv4 and ipv6, enter [any].
Security policy setting
msh> ipsec ike {1|2|3|4|default} proc {apply|bypass|discard}
• Enter the separate setting number [1-4] or [default] and specify the security policy for the address
specified in the selected setting.
• To apply IPsec to the relevant packets, specify [apply]. To not apply IPsec, specify [bypass].
• If you specify [discard], any packets that IPsec can be applied to are discarded.
• Not specifying a security policy displays the current setting.
Security protocol setting
msh> ipsec ike {1|2|3|4|default} proto {ah|esp|dual}
• Enter the separate setting number [1-4] or [default] and specify the security protocol.
• To specify AH, enter [ah]. To specify ESP, enter [esp]. To specify AH and ESP, enter [dual].
• Not specifying a protocol displays the current setting.
