Page #228 background image
Error Code Cause Solution
W0206-002
The user attempted
authentication from an
application on the "System
Settings" screen, where only
the administrator has
authentication ability.
Only the administrator has
login privileges on this screen.
Log in as a general user from
the application's login screen.
W0206-003
An authentication error
occurred because the user
name contains a space, colon
(:), or quotation mark (").
Recreate the account if the
account name contains any of
these prohibited characters.
If the account name was
entered incorrectly, enter it
correctly and log in again.
W0207-001
An authentication error
occurred because the Address
Book is being used at another
location.
Wait a few minutes and then try
again.
W0406-101
Authentication cannot be
completed because of the high
number of authentication
attempts.
Wait a few minutes and then try
again.
If the situation does not return to
normal, make sure that an
authentication attack is not
occurring.
Notify the administrator of the
screen message by e-mail, and
check the system log for signs of
an authentication attack.
W0400-102
Kerberos authentication failed
because the server or security
module is not functioning
correctly.
1. Make sure that the server is
functioning properly.
2. Make sure that the security
module is installed.
W0406-104
1. Cannot connect to the
authentication server.
Make sure that connection to
the authentication server is
possible.
Use the PING Command to
check the connection.
9. Troubleshooting
226
9

Table of Contents

Other manuals for Ricoh Aficio MP C2050

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Ricoh Aficio MP C2050 and is the answer not in the manual?

Ricoh Aficio MP C2050 Specifications

Ricoh Aficio MP C2050

General Specifications IconGeneral Specifications
output speed20 ppm BW & Full-Color
warm-up time25 seconds
first copy time full-color9.5 seconds
copy resolution600 x 600 dpi
original capacity50 sheets
dimensions23.1" x 25.8" x 33.3" (587 x 655 x 845 mm)
weight220 lbs
power requirements120V, 60Hz, 12A
Printer Controller IconPrinter Controller
cpuRM7035C @ 533MHz
memory768 MB (512 MB + 256 MB) RAM (Standard); 1GB RAM (Maximum)
max. print speed20 ppm BW & Full-Color
max. print resolution1200 x 1200 dpi
standard interfaces10Base-T/100Base-TX Ethernet (RJ-45), USB 2.0 Device, USB 2.0 Host I/F
Scanner Specifications IconScanner Specifications
scanner resolutionFrom 100 to 600 dpi (1200 dpi for TWAIN)
scanning speed bw41 ipm
scanning speed full-color26 ipm
scan area main scan11.7" (297mm)
scan area sub scan17" (432mm)

Ricoh Aficio MP C2550

General Specifications IconGeneral Specifications
output speed25 ppm BW & Full-Color
warm-up time25 seconds
first copy time full-color9.5 seconds
copy resolution600 x 600 dpi
original capacity50 sheets
dimensions23.1" x 25.8" x 33.3" (587 x 655 x 845 mm)
weight220 lbs
power requirements120V, 60Hz, 12A
Printer Controller IconPrinter Controller
cpuRM7035C @ 533MHz
memory768 MB (512 MB + 256 MB) RAM (Standard); 1GB RAM (Maximum)
max. print speed25 ppm BW & Full-Color
max. print resolution1200 x 1200 dpi
standard interfaces10Base-T/100Base-TX Ethernet (RJ-45), USB 2.0 Device, USB 2.0 Host I/F
Scanner Specifications IconScanner Specifications
scanner resolutionFrom 100 to 600 dpi (1200 dpi for TWAIN)
scanning speed bw41 ipm
scanning speed full-color26 ipm
scan area main scan11.7" (297mm)
scan area sub scan17" (432mm)
