Error Code Cause Solution
L0400-210
Failed to obtain user
information in LDAP search.
The login attribute's search
criteria might not be specified
or the specified search
information is unobtainable.
Make sure the login name
attribute is specified correctly.
L0406-003
An authentication error
occurred because the user
name contains a space, colon
(:), or quotation mark (").
Recreate the account if the
account name contains any of
these prohibited characters.
If the account name was
entered incorrectly, enter it
correctly and log in again.
L0409-000
Authentication timed out
because the server did not
respond.
Contact the server or network
administrator.
If the situation does not return to
normal, contact your service
representative.
L0511-000
The authentication server login
name is the same as a user
name already registered on the
machine. (Names are
distinguished by the unique
attribute specified in the LDAP
authentication settings.)
1. Delete the old, duplicated
name or change the login
name.
2. If the authentication server
has just been changed, delete
the old name on the server.
L0607-001
An authentication error
occurred because the Address
Book is being used at another
location.
Wait a few minutes and then try
again.
L606-004
Authentication failed because
the user name contains
language that cannot be used
by general users.
Do not use "other", "admin",
"supervisor" or "HIDE*" in
general user accounts.
L0612-005
Authentication failed because
no more users can be
registered. (The number of
users registered in the Address
Book has reached capacity.)
Ask the user administrator to
delete unused user accounts in
the Address Book.
Authentication Does Not Work Properly
235
9

Table of Contents

Other manuals for Ricoh Aficio MP C2050

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Ricoh Aficio MP C2050 and is the answer not in the manual?

Ricoh Aficio MP C2050 Specifications

Ricoh Aficio MP C2050

General Specifications IconGeneral Specifications
output speed20 ppm BW & Full-Color
warm-up time25 seconds
first copy time full-color9.5 seconds
copy resolution600 x 600 dpi
original capacity50 sheets
dimensions23.1" x 25.8" x 33.3" (587 x 655 x 845 mm)
weight220 lbs
power requirements120V, 60Hz, 12A
Printer Controller IconPrinter Controller
cpuRM7035C @ 533MHz
memory768 MB (512 MB + 256 MB) RAM (Standard); 1GB RAM (Maximum)
max. print speed20 ppm BW & Full-Color
max. print resolution1200 x 1200 dpi
standard interfaces10Base-T/100Base-TX Ethernet (RJ-45), USB 2.0 Device, USB 2.0 Host I/F
Scanner Specifications IconScanner Specifications
scanner resolutionFrom 100 to 600 dpi (1200 dpi for TWAIN)
scanning speed bw41 ipm
scanning speed full-color26 ipm
scan area main scan11.7" (297mm)
scan area sub scan17" (432mm)

Ricoh Aficio MP C2550

General Specifications IconGeneral Specifications
output speed25 ppm BW & Full-Color
warm-up time25 seconds
first copy time full-color9.5 seconds
copy resolution600 x 600 dpi
original capacity50 sheets
dimensions23.1" x 25.8" x 33.3" (587 x 655 x 845 mm)
weight220 lbs
power requirements120V, 60Hz, 12A
Printer Controller IconPrinter Controller
cpuRM7035C @ 533MHz
memory768 MB (512 MB + 256 MB) RAM (Standard); 1GB RAM (Maximum)
max. print speed25 ppm BW & Full-Color
max. print resolution1200 x 1200 dpi
standard interfaces10Base-T/100Base-TX Ethernet (RJ-45), USB 2.0 Device, USB 2.0 Host I/F
Scanner Specifications IconScanner Specifications
scanner resolutionFrom 100 to 600 dpi (1200 dpi for TWAIN)
scanning speed bw41 ipm
scanning speed full-color26 ipm
scan area main scan11.7" (297mm)
scan area sub scan17" (432mm)
