1. Connecting the Machine
This chapter describes how to connect the machine to the network and specify
the network settings.
Connecting to the Interfaces
This section explains how to identify the machine’s interface and connect the
machine according to the network environment.
1. IEEE 1394 ports (optional)
Ports for connecting the IEEE 1394 inter-
face cable
2. USB2.0 port
Port for connecting the USB2.0 interface
cable
3. 10BASE-T/100BASE-TX port
Port for connecting the 10BASE-T or
100BASE-TX cable
4. IEEE 1284 port (optional)
Port for connecting the IEEE 1284 inter-
face cable
5. Wireless LAN port (optional)
Port for using the wireless LAN
Note
❒ You cannot install two or more of the
options below: IEEE 1394 interface
board, IEEE 1284 interface board,
IEEE 802.11b wireless LAN
AQT002S
