Ricoh Aficio SG 7100DN - Air Purge Detection Switch

3. Remove the 2nd registration sensor ( x 1, x 3).
Air Purge Detection Switch
Preparation
• Duplex unit ( p.48)
• Rear cover ( p.51 "Rear Cover, Top Cover")
• Top cover ( p.51 "Rear Cover, Top Cover")
• Right cover ( p.54)
• Unlock the carriage ( p.64 "Unlocking, Moving the Carriage")
4. Replacement and Adjustment
108
