Ricoh Aficio SG 7100DN - Bypass Drawer Connector

5. Separate the bracket and switch ( x 2).
6. After re-installing the maintenance unit, execute manual cleaning.
Bypass Drawer Connector
Preparation
• Duplex unit ( p.48)
• Rear cover ( p.51 "Rear Cover, Top Cover")
• Top cover ( p.51 "Rear Cover, Top Cover")
• Fan, Fan bracket ( p.91 "Fan")
• Vertical motor ( p.88)
Sensors, Switches
117
