• Replacing a lithium battery with any type other than the one prescribed for use on the board could
lead to an explosion or damage to the PCB.
• Never discard used batteries by mixing them with other trash.
• Remove used batteries from the work site and dispose of them in accordance with local laws and
regulations regarding the disposal of such items.
Conventions Used in this Manual
Symbols and Abbreviations
This manual uses several symbols.
Symbol What It Means
Clamp
Clip ring
Connector
E-ring
FFC (Flat Film Connector)
Hook
Pointer (cross-reference to another manual section)
Screw
Spring
Standoff
Timing Belt
This manual uses the following abbreviations.
7
