Ricoh Aficio SG 7100DN User Manual

Calibrate Humidity/Temperature for Duplex (DFU)
1-012-001 CHG:TEMP:B Calibrate Humidity Setting for Duplex
1-012-002 CHG:HUMI:B Calibrate Temperature Setting for Duplex
Set Charge Area
1-012-003 CHG:AREA:EDGE:F Set Charge of Area for LE/TE: Simplex
Use this SP to set the size of the leading and trailing edges for the 1st side of paper. Do this setting
when you want to adjust pitch amount of the charge applied to the leading and trailing edges for
printing. The areas of the leading and trailing edges is shown below.
[0 to 0xff/0/1/---]
1-012-004 CHG:AREA:EDGE:B Set Charge of Area for LE/TE: Duplex
Use this SP to set the size of the midle area for the 1
st
ide of paper. Do this setting when you want to
adjust pitch amount of the charge applied to the leading and trailing edges for printing. The areas of
the leading and trailing edges is shown below.
[0 to 0xff/0/1/---]
1-012-005 CHG:AREA:MIDL:F Set Charge of Area for Middle: Simplex
Use this SP to set the size of the leading and trailing edges for the 1st side of paper. Do this setting
when you want to adjust pitch amount of the charge applied to the middle area for printing. The
middle area is shown below.
[0 to 0xff/0/1/---]
1-012-006 CHG:AREA:MIDL:B Set Charge of Area for Middle: Duplex
Use this SP to set the size of the leading and trailing edges for the 2nd side of paper. Do this setting
when you want to adjust pitch amount of the charge applied to the middle area for printing. The
middle area is shown below.
[0 to 0xff/0/1/---]
SP Mode Service Tables
39

Ricoh Aficio SG 7100DN Specifications

General

Maximum Print Resolution	1200 x 1200 dpi
Duplex Printing	Yes
Operating System Compatibility	Windows, Mac, Linux
Print Speed (Black)	29 ppm
Print Speed (Color)	29 ppm
Connectivity	USB 2.0, Ethernet
Paper Size	A4, A5, B5, Letter, Legal
