SH-P1 Training
56
Slide 56
Paper Size Detection Table
ONONOFFHLT SEF
ONOFFOFFLT SEF
OFFOFFOFFLG SEF
OFFOFFONCustom size
OFFONOFFB5 SEF
ONOFFONA5 SEF
OFFONONA4 SEF
SN3SN2SN1Size
The paper size detection sensor board determines the paper
size based on the switch combination as shown in the paper
size detection table above.
No additional notes.
