Ricoh Aficio SP 5200DN Training

SH-P1 Training
94
Slide 94
Electrical Component Layout
1. Paper end sensor
2. Remaining paper
sensors
3. Transport sensor
4. Tray set switch
5. Paper size
detection sensor
6. PFU motor
7. PFU board
8. Feed clutch
1
2
3
4
5
6
7
8
 Components 3, 6, 7, and 8 are unique to the paper tray units.
