SH-P1 Training
93
Slide 93
Overview
Each paper tray unit (PFU) has its own feed mechanism.
Like the standard tray, each PFU holds 550 sheets of
paper.
If the machine is installed on the floor, the bottom PFU
must be a TK1130 (M376) unit (Has casters)
The paper trays are almost exactly the same as the
standard paper tray. The only difference is that the front
plate is slightly higher on the PFU trays.
Standard TrayPFU Tray
