SH-P1 Training
80
Slide 80
Fusing Pressure Adjustments
Service Adjustment
To increase fusing pressure move the pressure springs [B] from the upper
notch [C] to the lower notch [D].
User Adjustment for Envelopes
The user can change the fusing pressure with the envelope lever [A]. Less
pressure is needed for envelopes, which are thicker than normal paper.
Raise the lever (①) to reduce the pressure. This prevents jams and
wrinkling when printing on envelopes.
Lower the lever to (②) return pressure to normal for all other print jobs.
Normally this lever should be down.
[C]
[D]
You may need to increase pressure if the customer complains of insufficient
fusing. The factory setting is the upper notch.
