1. Pull the opening lever on the front cover, and then carefully lower the front cover.
CES141
2. Lower the fusing unit lever, and pull out the jammed paper carefully.
CES257
Pull the paper downward to remove it. Do not pull it upward.
CES144
If you cannot find the jammed paper, check for it by pulling down the guide.
