Ricoh Aficio SP C240SF - Page 363

CES145
3. Pull up the fusing unit levers.
CES258
4. Using both hands, carefully push up the front cover until it closes.
CES142
• When closing the front cover, push the upper area of the cover firmly. After closing the cover,
check that the error is cleared.
If paper jams inside a tray
If paper jams in tray 1 or 2, follow the procedure below to remove it.
Paper Feed Problems
361
9
