• Do not touch the ID chip on the side of the print cartridge as indicated in the illustration below.
CES032
1. Remove the plastic bag.
2. Lift the machine with another person using the inset grips on both sides of the machine.
CES052
3. Remove the protective materials attached on the machine's exterior. Do not remove tapes
going into the inside of the machine.
CES155
The actual machine may come with protective materials attached in different positions. Make sure
to check the machine's exterior for all protective materials, and remove them completely.
