Ricoh Aficio SP C242DN

4. Pinch the extender in the PUSH direction, and then pull out the extender until it stops (you
will hear a click).
CER084
After extension, make sure the arrows on the extender and tray are aligned.
CER085
5. Pinch the clip on the side paper guide, and then slide it to match the paper size.
CER102
Loading Paper
77
5
