Ricoh Aficio SP C820DN

To Next Page

To Previous Page

6. Remove the jammed staples.

BVM249S

7. Push the face plate down until it clicks.

BMV250S

8. Holding the lever on the cartridge, push the cartridge gently into the staple unit until it clicks.

BMV092S

9. Troubleshooting

224
