BMW050S

5. Pull the tray of the 500-sheet paper feed unit out slowly until it stops, then lift the front of

the tray slightly, and pull it out completely.

BMW051S

Place the tray on a flat surface.

6. Attach a screw in the hole on the left side of the tray opening to secure it to the paper feed

unit.

Tighten the screw firmly using a coin.

BMW052S

2. Installing Options
