51
3.2 Installing the Charge Roller Unit and Cleaning Unit
for PCU
1. Holding the ends of the cleaning unit for PCU where the purple labels are,
attach the unit so that the triangular marks on it match up with those at the
bottom of the PCDU.
CEZ307
2. Rotate the cleaning unit for PCU to the left.
CEZ132
3. Pull up the lock lever to lock the cleaning unit for PCU.
CEZ114
To Next Page
