7.2 Installing the Fusing Unit and Cleaning Unit for
Fusing Unit
1. Insert the two shafts into the holes on the right (A).
A
B
CEZ161
2. Lower the left end over the lever and onto the positioning pin.
3. Make sure that the left-end plate is flat around the positioning pin (B).
4. Reattach the black screw.
CEZ164
