Ricoh D074 Series Replacement Guide

83
6. Remove the black screw (A), and then push the lock lever to the right (B).
B
A
CEZ125
7. Pull up the cover D3.
CEZ126
8. Pull up the handle (A) and grip the front of the fusing unit (B).
A
B
CEZ144
Note: The fusing unit weighs about 17 kg (37 lb.).
