Ricoh GXR User Manual

First-time user? read this.
22
Taking a Photograph
1
Focus.
Frame your subject in the center of the picture
display and press the shutter-release button halfway
to set focus and exposure.
4:3 N
If the camera is able to focus, the
focus frames for the objects in
focus are displayed in green
(up to nine frames).
If the camera is unable to focus, the
focus frame blinks red and the
autofocus/ash lamp blinks
green.
Autofocus/ash lamp
Focus frame
2
Take a picture.
Gently press the shutter-release button the rest
of the way down to take the picture. The picture
is displayed immediately after shooting for a few
seconds (page 142), and saved to internal memory
or memory card.

Ricoh GXR Specifications

General

Megapixel	10 MP
Camera type	SLR Camera Body
Sensor type	CMOS
Image stabilizer	Yes
Image sensor size	- \
Maximum image resolution	4288 x 2848 pixels
Still image resolution(s)	-
Interface	USB 2.0, NTSC, HDMI
Minimum RAM	512 MB
Minimum processor	500 MHz
Camera shutter speed	- s
Minimum storage drive space	160 MB
Compatible operating systems	Windows 2000/XP/Vista/7, Mac OS 9.0-9.2.2/X 10.1.2-10.6.4
Focal length (35mm film equivalent)	- mm
Optical zoom	3 x
Auto focusing (AF) modes	Contrast Detection Auto Focus, Multi Point Auto Focus, Spot Auto Focus
Light exposure modes	Aperture priority AE, Auto, Manual, Shutter priority AE
Flash modes	Manual, Red-eye reduction, Slow synchronization
Internal memory	84 MB
Compatible memory cards	SD, SDHC
HD type	Not supported
Video formats supported	AVI
Maximum video resolution	1280 x 720 pixels
Display diagonal	3 \
Display resolution (numeric)	920000 pixels
PictBridge	No
USB version	2.0
Scene modes	Night, Portrait, Sports, Landscape (scenery)
Image editing	resizing, rotating
Camera playback	movie, single image
Self-timer delay	2 s
Playback zoom (max)	16 x
Product color	Black
Battery type	DB-90
Storage temperature (T-T)	3648 x 2736 °C
Operating temperature (T-T)	0 - 40 °C

Weight and Dimensions

Depth	37.5 mm
Width	113.9 mm
Height	70.2 mm
Weight	160 g
