Electrical Components
J012/J013/J014 6-12 SM
Scanner Unit
1 Operation Panel
2 Exposure Lamp
3 Lamp Regulator
4 CCD Board
5 Scanner Motor
6 Network Communication Unit
7 Main Board
8 Network Interface Card
