Ricoh P C600 User Manual

2. Turn the printer off and unplug the power cord.
3. Loosen the two screws and remove the slot cover.
EAG339
The removed cover will not be reused.
4. Fully insert the interface board.
EAG340
Check that the interface board is firmly connected to the controller board.
5. Tighten the two screws to secure the interface board.
EAG378
6. Plug in the power cord, and then turn on the printer.
7. Print the configuration page to confirm that the board was attached correctly.
Installing Options
29

Ricoh P C600 Specifications

General

Type	Original
Printing colors	Black
Quantity per pack	1 pc(s)
Built-in drum unit	-
Brand compatibility	Ricoh
Black toner page yield	18000 pages
Print technology	Laser printing

Weight and Dimensions

Package type	Box
Package weight	379 g
