Ricoh P C600 User Manual

5. Tighten the two screws to secure the interface board.
EAG342
6. Plug in the power cord, and then turn on the printer.
7. Print the configuration page to confirm that the board was attached correctly.
• Check that the board was correctly installed by printing the configuration page. If it is correctly
installed, "Parallel Interface" will appear for "Device Connection" on the configuration page. For
details about printing the configuration page, see "Test Printing", Operating Instructions.
• If the board was not installed properly, repeat the procedure from the beginning. If it cannot be
installed correctly even after trying the installation a second time, contact your sales or service
representative.
Installing the USB device server
The USB device server is an interface board that adds an Ethernet port to the printer.
With this device installed, two Ethernet cables can be connected at the same time using the standard
port on the printer and an additional port on the USB device server. You can assign different IP
addresses to each port, so the printer can print jobs from different network segments.
Procedure for installing the USB device server
1. Check the contents of the package.
2. Turn the printer off and unplug the power cord.
Installing Options
31
