As shown below, the areas within 1.3 mm (0.05 inches) of the detection marks are not subject to
detection. The detection marks are printed according to the specified margin settings.
1. Margins
2. Detection marks
3. 1.3 mm (0.05 inches)
4. Areas not subject to detection
Margins (mm/inch) 1.0/0.04 2.0/0.08 3.0/0.12 4.0/0.16 5.0/0.20
Areas not subject to detection
(mm/inch)
5.0/0.20 6.0/0.24 7.0/0.28 8.0/0.32 9.0/0.35
If you uncheck [Enable], you can enter any value in [Non-detection range].
Threshold Setting
31
