1. Margins (vertical): 4.0 mm (0.16 inches) by default
2. 1.0 mm (0.04 inches) (Space for printing inspection patterns)
3. Margins (horizontal): 2.0 mm (0.08 inches) by default
4. Inspection patterns
With detection marks for [Image Position Feedback Correction]
By default, the required margins are 8.0 mm (0.3inches) at the top and bottom and 3.0 mm (0.12
inches) at each side.
1. Margins (vertical): 4.0 mm (0.16 inches) by default
2. Detection marks for [Image Position Feedback Correction]
3. 1.3 mm (0.05 inches) (Margin for printing detection marks)
4. Margins (horizontal): 2.0 mm (0.08 inches) by default
5. Inspection patterns
6. 2.7 mm (0.1 inches)
Add Print Result ID Number
Click [ ] to display this item. Select whether or not to add identification numbers to the printed copies.
However, identification numbers can be added only if the settings have been configured to add
1. Operating and Settings
28
