Ricoh SG 7100DN - Page 103

3. Load paper with the print side face down but not over the limit mark.
CHU100
4. Squeeze the front end paper guide, and then slide it to touch the edge of the paper.
CHU099
5. Push the tray gently in until it stops.
1
2
CTW056
Before you push Tray 1 in, make sure the output ramp is closed.
Loading Paper
101
