Removing Paper Jammed in Tray 1
1. Hold the grip on Tray 1, lift the tray slightly ( ), and then pull it out ( ).
1
2
CHU053
Pull the tray completely out. Take care not to drop it.
2. Open the output ramp, and then remove the jammed paper.
CHU057
If you cannot remove the jammed paper or it is difficult to remove, the paper may be jammed
inside the machine. Examine the paper carefully and remove.
3. Close the output ramp.
CHU056
