Ricoh SG 7100DN - Extending the Paper Tray to Load Paper

6. Pull out the output ramp extension.
CHU055
Extending the Paper Tray To Load Paper
1. Hold the tray grip, pull the tray halfway out, lift it slightly ( ), and then pull it out further
( ).
1 2
CHU077
Pull the tray out completely. Take care not to drop it.
After pulling the tray out, check that no paper remains in the machine. If there is any remaining
paper sheets, remove it.
2. Slide the tabs on both sides of the tray, and then release the lock.
CTW029
2. Preparing for Printing
102
