Ricoh SP C262SFNw - Cleaning the Auto Document Feeder

Cleaning the Auto Document Feeder
1. Lift the ADF.
Be careful not to hold the input tray when lifting the ADF, for the tray might be damaged.
2. Clean the parts indicated with arrows with a soft damp cloth and then wipe the same
parts with a dry cloth to remove any remaining moisture.
DAC005
When using SP C261SFNw/SP C262SFNw, proceed to Step 3.
3. Close the ADF.
4. Open the ADF cover.
DUE321
2
1
Cleaning the Auto Document Feeder
337
