Quick Installation
This section explains how to install the PCL 6 printer driver and configure the settings to use the printer
via a network or USB connection easily.
Quick Installation via a Network
Quick installation via a network allows you to install the PCL 6 printer driver via a network connection
and configure the settings to use the printer in a network.
1. Click [Install from Disk] on the installer screen.
2. Click [Network Printer(s)] on the installer screen.
3. The software license agreement appears in the [License Agreement] dialog box. After
reading the agreement, click [I accept the agreement.], and then click [Next >].
4. Click [Next >].
5. Select the printer model you want to use in the [Select Printer] dialog box.
6. Click [Install].
7. When the port setting screen appears, specify a port.
8. Configure the user code, default printer, and shared printer as necessary.
9. Click [Continue].
The installation starts.
10. Click [Finish].
When you are prompted to restart your computer, restart it by following the instructions that
appear.
11. Click [Exit] in the first window of the installer, and then remove the CD-ROM.
Quick Installation via a USB Connection
Quick installation via a USB connection allows you to install the PCL 6 printer driver via a USB
connection and configure the settings to connect the printer to a computer.
1. Click [Install from Disk] on the installer screen.
2. Click [USB printer(s)] on the installer screen.
3. The software license agreement appears in the [License Agreement] dialog box. After
reading the agreement, click [I accept the agreement.], and then click [Next >].
4. Select the method to install a printer driver, and then click [Next >].
5. Select the printer model you want to use, and then click [Next >].
3. Installing the Driver
24

Table of Contents

Other manuals for Ricoh SP C360DNW

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Ricoh SP C360DNW and is the answer not in the manual?

Ricoh SP C360DNW Specifications

General IconGeneral
ColorYes
Print technologyLED
Maximum resolution1200 x 1200 DPI
Duplex printing modeAuto
Warm-up time (from sleep mode)9.9 s
Time to first page (black, normal)7.2 s
Time to first page (color, normal)8.6 s
Print speed (black, normal quality, A4/US Letter)30 ppm
DisplayLCD
Product colorBlack, Grey
Market positioningHome & office
Display number of lines4 lines
AC input voltage120 V
AC input frequency60 Hz
Power consumption (max)533.7 W
Power consumption (standby)0.83 W
Power consumption (printing)471.3 W
Energy Star Typical Electricity Consumption (TEC)0.411 kWh/week
Printing colors-
Maximum duty cycle75000 pages per month
Sustainability certificatesEPEAT Silver, ENERGY STAR
Sound pressure level (printing)- dB
Total input capacity- sheets
Total output capacity200 sheets
Duplex media weight56 - 163 g/m²
Paper tray media typesBond paper, Card stock, Coated paper, Envelopes, Glossy paper, Labels, Letterhead, Plain paper, Pre-Printed, Recycled paper, Thick paper, Thin paper
Paper tray media weight56 - 220 g/m²
Duplex media weight (imperial)15 - 43 lbs
Paper tray media weight (imperial)16 - 59 lbs
Wi-Fi standards802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology10/100/1000Base-T(X)
Security algorithmsSMTP-AUTH, SSL/TLS, WEP
Ethernet LAN data rates10, 100, 1000 Mbit/s
Mobile printing technologiesApple AirPrint, Google Cloud Print, Mopria Print Service
Mac operating systems supportedMac OS X 10.9 Mavericks, Y
Other operating systems supportedIBM AS/400
Server operating systems supportedWindows Server 2008 R2, Windows Server 2012 R2
Windows operating systems supportedWindows 10, Windows 7, Windows 8, Windows 8.1, Windows Vista
Cables includedAC
Included cartridge capacity (CMY)1500 pages
Included cartridge capacity (black)2500 pages
Weight and Dimensions IconWeight and Dimensions
Depth515 mm
Width400 mm
Height360 mm
