Ricoh SP C360DNW - Guide to Names and Functions of Components

Guide to Names and Functions of Components
Guide to Components
• Do not obstruct the machine's vents. Doing so risks fire caused by overheated internal
components.
Exterior: Front view
DUP302
10
11
13
6
7
8
9
1
2
3
5
14
15
12
4
1. Top cover
Open this cover to replace the toner or black drum unit/color drum units.
2. Standard tray
Output is stacked here with the print side down.
3. Control panel
You can set the display up with your hands. Adjust the angle of it to see clearly.
1. Getting Started
10
