Loading Paper into Paper Trays
In the following example procedure, paper is loaded into Tray 1.
When loading paper, take care not to trap or injure your fingers.
When loading paper, pull the paper tray completely out from the printer and set the stack of paper
straight down on the tray. Loading the paper from a diagonally downward direction may cause the
printer to malfunction.
For details about trays that can be loaded for each paper size and type, see page 49 "Paper
Size Specifications" and page 52 "Paper Type Specifications".
Be sure to select the correct paper size and feed direction using the paper size dial on the tray.
Otherwise, the printer might be damaged, or printing problems might occur.
To use the paper size and feed direction other than those indicated on the paper size dial, set the
dial to " ", and set the paper size using the control panel.
Make sure the paper stack does not exceed the upper limit mark inside the paper tray. Excessive
stacking can cause paper jams.
If paper jams occur frequently, flip the paper stack in the tray.
Do not mix different types of paper in the same paper tray.
After loading paper, specify the paper size using the control panel or paper size dial, and paper
type using the control panel. When printing a document, specify the same paper size and type in
the printer driver as specified on the printer.
Do not move the side paper guides and end paper guide forcefully. Doing so may damage the
tray.
Do not slide the paper tray in forcefully when inserting the loaded tray into the printer. Otherwise,
the side and end guides or the paper guide of the bypass tray might move.
When loading label paper, load it one by one.
1. Pull out the paper tray carefully. Adjust the paper size dial to match the size and feed
direction of paper in the paper tray.
Tray 1
2. Loading Paper
26

Table of Contents

Other manuals for Ricoh SP C360DNW

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Ricoh SP C360DNW and is the answer not in the manual?

Ricoh SP C360DNW Specifications

General IconGeneral
ColorYes
Print technologyLED
Maximum resolution1200 x 1200 DPI
Duplex printing modeAuto
Warm-up time (from sleep mode)9.9 s
Time to first page (black, normal)7.2 s
Time to first page (color, normal)8.6 s
Print speed (black, normal quality, A4/US Letter)30 ppm
DisplayLCD
Product colorBlack, Grey
Market positioningHome & office
Display number of lines4 lines
AC input voltage120 V
AC input frequency60 Hz
Power consumption (max)533.7 W
Power consumption (standby)0.83 W
Power consumption (printing)471.3 W
Energy Star Typical Electricity Consumption (TEC)0.411 kWh/week
Printing colors-
Maximum duty cycle75000 pages per month
Sustainability certificatesEPEAT Silver, ENERGY STAR
Sound pressure level (printing)- dB
Total input capacity- sheets
Total output capacity200 sheets
Duplex media weight56 - 163 g/m²
Paper tray media typesBond paper, Card stock, Coated paper, Envelopes, Glossy paper, Labels, Letterhead, Plain paper, Pre-Printed, Recycled paper, Thick paper, Thin paper
Paper tray media weight56 - 220 g/m²
Duplex media weight (imperial)15 - 43 lbs
Paper tray media weight (imperial)16 - 59 lbs
Wi-Fi standards802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology10/100/1000Base-T(X)
Security algorithmsSMTP-AUTH, SSL/TLS, WEP
Ethernet LAN data rates10, 100, 1000 Mbit/s
Mobile printing technologiesApple AirPrint, Google Cloud Print, Mopria Print Service
Mac operating systems supportedMac OS X 10.9 Mavericks, Y
Other operating systems supportedIBM AS/400
Server operating systems supportedWindows Server 2008 R2, Windows Server 2012 R2
Windows operating systems supportedWindows 10, Windows 7, Windows 8, Windows 8.1, Windows Vista
Cables includedAC
Included cartridge capacity (CMY)1500 pages
Included cartridge capacity (black)2500 pages
Weight and Dimensions IconWeight and Dimensions
Depth515 mm
Width400 mm
Height360 mm
