8. Lift the front side of the tray, and then slide it into the printer carefully until it stops.
DUP203
To avoid paper jams, make sure the tray is securely inserted.
• When loading paper larger than A4 or 8
1
/
2
× 11 into Tray 1, extend the tray. For details, see
page 30 "When Loading Paper Larger than A4 or 8
1
/
2
× 11".
• Letterhead paper must be loaded in a specific orientation. For details, see page 34 "Loading
Orientation-Fixed Paper or Two-Sided Paper".
• You can load envelopes into Tray 1. Envelopes must be loaded in a specific orientation. For
details, see page 36 "Loading Envelopes".
When Loading Paper Larger than A4 or 8
1
/
2
× 11
When loading paper larger than A4 or 8
1
/
2
× 11 into Tray 1, extend the tray.
1. Pull the tray out of the printer.
For details, see Steps 1 and 2 on page 26 "Loading Paper into Paper Trays".
2. Slide the catches inwards to unlock the tray, and then slide the tray until it stops.
2
2
1
1
DSE122
