13. Ventilation holes
Prevent overheating.
14. Front cover open lever
Pull this lever to open the front cover.
15. Paper size dial
Use this dial to specify the paper size. To use a paper size that is not indicated on the paper size dial, set the
dial to " ". If this is the case, set the paper size using the control panel.
Exterior: Rear view
1. Ventilation holes
Prevent overheating.
2. Power connector
Connect the power cord to the printer. Insert the other end into an electrical outlet.
3. Cable cover
Remove this cover to connect various cables.
4. Rear cover
Raise this cover and attach the paper tray cover when loading paper larger than A4 or letter size paper.
5. Ethernet port
Use a network interface cable to connect the printer to a network.
6. USB port B
Use a USB cable to connect the printer to a computer.
1. Getting Started
12
