In the administrator mode, you can configure various printer settings.
• When entering an IPv4 address, do not begin segments with zeros. For example: If the address is
"192.168.001.010", you must enter it as "192.168.1.10".
1. Start your Web browser.
2. Enter "http://(printer's IP address or host name)/" in your Web browser's address bar.
The top page of Web Image Monitor appears.
If the printer's host name has been registered on the DNS or WINS server, you can enter it.
When setting SSL, a protocol for encrypted communication, under the environment in which server
authentication is issued, enter "https://(printer's IP address or host name)/".
3. To log in to Web Image Monitor in the administrator mode, click [Login] on the top page.
The window for entering the login user name and password appears.
4. Enter your login user name and password, and then click [Login].
For details about the login user name and password, contact your administrator.
Depending on the configuration of your Web browser, the login user name and password might be
saved. If you do not want to save them, configure your Web browser's settings so that this
information is not saved.
5
4
3
2
1
DUP326
1. Menu area
Displays the content of a selected menu item.
2. Header area
Displays the dialog box for switching to the user mode and administrator mode and the menu for each mode.
Also displays the link to Help and dialog box for keyword search.
Monitoring and Configuring the Printer
23

Ricoh SP C360DNW Specifications

General

Color	Yes
Print technology	LED
Maximum resolution	1200 x 1200 DPI
Duplex printing mode	Auto
Warm-up time (from sleep mode)	9.9 s
Time to first page (black, normal)	7.2 s
Time to first page (color, normal)	8.6 s
Print speed (black, normal quality, A4/US Letter)	30 ppm
Display	LCD
Product color	Black, Grey
Market positioning	Home & office
Display number of lines	4 lines
AC input voltage	120 V
AC input frequency	60 Hz
Power consumption (max)	533.7 W
Power consumption (standby)	0.83 W
Power consumption (printing)	471.3 W
Energy Star Typical Electricity Consumption (TEC)	0.411 kWh/week
Printing colors	-
Maximum duty cycle	75000 pages per month
Sustainability certificates	EPEAT Silver, ENERGY STAR
Sound pressure level (printing)	- dB
Total input capacity	- sheets
Total output capacity	200 sheets
Duplex media weight	56 - 163 g/m²
Paper tray media types	Bond paper, Card stock, Coated paper, Envelopes, Glossy paper, Labels, Letterhead, Plain paper, Pre-Printed, Recycled paper, Thick paper, Thin paper
Paper tray media weight	56 - 220 g/m²
Duplex media weight (imperial)	15 - 43 lbs
Paper tray media weight (imperial)	16 - 59 lbs
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology	10/100/1000Base-T(X)
Security algorithms	SMTP-AUTH, SSL/TLS, WEP
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Mobile printing technologies	Apple AirPrint, Google Cloud Print, Mopria Print Service
Mac operating systems supported	Mac OS X 10.9 Mavericks, Y
Other operating systems supported	IBM AS/400
Server operating systems supported	Windows Server 2008 R2, Windows Server 2012 R2
Windows operating systems supported	Windows 10, Windows 7, Windows 8, Windows 8.1, Windows Vista
Cables included	AC
Included cartridge capacity (CMY)	1500 pages
Included cartridge capacity (black)	2500 pages

Weight and Dimensions

Depth	515 mm
Width	400 mm
Height	360 mm
