3. The paper edge stopper fails to push back the protruding leading edge and align the sheet as
required.
Paper feed direction
Stacker shift tray
Paper edge
stopper
Paper exit
Paddle
CEZ579
4. Stacked sheets are not aligned properly.
Paper feed direction
Stacker shift tray
Paper edge
stopper
Paper exit
Paddle
CEZ580
Solution:
Curl the sheet upward.
To do this, the decurler unit must be attached.
1. In the [Machine: Paper Feed/ Output] group on the [Adjustment Settings for Operators]
menu, set 0304: [Correct Output Paper Curl] to " Curl Correction Level: Small".
2. Print the image. Has the problem been resolved?
Yes Finished!
No Go to the next step.
3. Set 0304: [Correct Output Paper Curl] to " Curl Correction Level: Large".
4. Print the image. Has the problem been resolved?
Yes Finished!
High Capacity Stacker
153
