[Corct Temp: Init Fd: Clr/Sp], [Corct Temp: Init Fd: White]
• [S]
[Corct Temp: Init Fd: Clr/Sp], [Corct Temp: Init Fd: White]
• [BW/FC/FCS: Fuser Setting HQ]
[Corct Temp: Initial Feed]
• [FCS: Fuser Setting HQ]
[Corct Temp: Init Fd: Clr/Sp], [Corct Temp: Init Fd: White]
• [S: Fuser Setting HQ]
[Corct Temp: Init Fd: Clr/Sp], [Corct Temp: Init Fd: White]
3. Select 1232: [Fusing Temperature], and then set the value in the following corresponding
settings to "5°C".
• [BW/FC/FCS]
[Corct Temp: Pre-Feed]
• [FCS]
[Corct Temp: Pre-Fd: Clr/Sp], [Corct Temp: Pre-Fd: White]
• [S]
[Corct Temp: Pre-Fd: Clr/Sp], [Corct Temp: Pre-Fd: White]
• [BW/FC/FCS: Fuser Setting HQ]
[Corct Temp: Pre-Feed]
• [FCS: Fuser Setting HQ]
[Corct Temp: Pre-Fd: Clr/Sp], [Corct Temp: Pre-Fd: White]
• [S: Fuser Setting HQ]
[Corct Temp: Pre-Fd: Clr/Sp], [Corct Temp: Pre-Fd: White]
4. Print 10 or more A3 sheets.
5. Has the problem been resolved?
Yes Go to the next step.
No Proceed to "(e) Decrease the heat roller temperature".
6. Is the toner fusibility within the permissible range?
Yes Finished!
No Contact your service representative.
Uneven Density
