Ricoh TR5050 - Page 12

1.Detailed Descriptions
8
• When the cutter is locked, the cutting edge of the cutter may be chipped. After unlocking
the cutter, check if there is any problem with the cutting edge.
Unlocking Procedure
1.
Remove the rear cover. (Rear Cover)
2. Press the cutter shifting button at the lower left of the board to move the cutter to its home position.
