2.Replacement and Adjustment
9
2. Replacement and Adjustment
Common Procedures
Before You Begin
Remove the covers, door, and tray in this order for major maintenance and cleaning:
Rear cover ( x3)
Left upper cover ( x2)
Top cover ( x5)
Front door ( x4)
Left bottom cover ( x2)
Tray unit ( x2, x2)
