2.Replacement and Adjustment
56
2. Remove the switch bracket [A] ( x2).
3. On the side, pull out three standoffs to free the harness [A].
4. Disconnect the switch [B] ( x2).
5. Remove the switch cover [A] ( x2).
6. Press in on both sides of the switch [A].
To Next Page
