Riello Array AR 2000 User Manual

68
SHUTDOWN
68
APPENDIX
APPENDIX
Menu item Sub item / Parameter Range Default Value Units User level
(187) Prog. Output 5.
0) Disabled
1) General Pump
2) CH Pump
3) DHW Pump
4) System Pump
5) Cascade Pump
6) Alarm Relay
7) Filling Valve
8) LPG Tank
9) External Igniter
10) Air Damper
14) Alarm Burner CC
15) Status Burner CC
16) Zone pump
17 )Mixing valve open
18 )Mixing valve closed
19) Anti-legionella pump
Managing: 2
Dependent: 2
2: Installer
(129) Flow Sensor
0) Disabled
1) General Pump
2) CH Pump
3) DHW Pump
4) System Pump
5) Cascade Pump
6) Alarm Relay
7) Filling Valve
8) LPG Tank
9) External Igniter
10) Air Damper
14) Alarm Burner CC
15) Status Burner CC
16) Zone pump
17) Mixing valve open
18) Mixing valve closed
19) Anti-legionella pump
Managing: 6
Dependent: 6
2: Installer
(130) Flow Scaling Factor
0) Disabled
6) Alarm Relay
10) Air Damper
11) HSI / ext. igniter
Managing: 0
Dependent: 0
2: Installer
(131) Min Pressure
0) Disabled
1) General Pump
2) CH Pump
3) DHW Pump
4) System Pump
5) Cascade Pump
6) Alarm Relay
7) Filling Valve
8) LPG Tank
9) External Igniter
10) Air Damper
14) Alarm Burner CC
15) Status Burner CC
16)Zone pump
17)Mixing valve open
18)Mixing valve closed
19)Anti-legionella pump
J3 1-7
Managing: 3 (3-
way valve CH)
Dependent: 3 (3-
way valve CH)
J3 2-7
Managing: 3 (3-
way valve DHW)
Dependent: 3 (3-
way valve DHW)
2: Installer
(132) Pressure Fill Hyst. 0.2…5.0 0.5 bar 2: Installer
(133) Mod. Pump dT 5…40 15 °C 2: Installer
(134) Mod. Pump Start Time 0…255 120 Sec. 2: Installer
(135) Mod. Pump Type
0. Wilo Yonos
1. Salmson
2. Grundfos
Grundfos 2: Installer
(136) Mod. Pump Mode
0. On/Off
1. Modulating
2-10 Fixed 20… 100%
Modulating 2: Installer
(137) Mod. Pump Min Power 0…100 30 % 2: Installer
