Riello NXC 021 - Setpoint Menu Parameters

PRO-DIALOG+
82
EN
SETPOINT menu
Name Format Value Units Description
csp1 - 29.7 to 20 12.0 °C Cooling setpoint 1.
csp2 - 29.7 to 20 12.0 °C Cooling setpoint 2.
hsp1 20 to 55 40.0 °C Heating setpoint 1.
hsp2 20 to 55 40.0 °C Heating setpoint 2.
hramp_sp 0.1 to 1.1 0.60 ^C Chargingspeed.
cauto_sp 3.9 to 50 24.0 °C Coolingswitchingsetpoint.
hauto_sp 0 to 46.1 18.0 °C Heatingswitchingsetpoint.
lim_sp1 0 to 100 100 % Limit setpoint 1
lim_sp2 0 to 100 100 % Limit setpoint 2
lim_sp3 0 to 100 100 % Limit setpoint 3
min_sct 26.7 to 55* 40 °C Condensingsetpointincaseofdesuperheateruse.
*50,iftheunitisequippedwithvariablespeedfan.
INPUT menu
Name Format Units Description
ONOFF_SW Open/Close - Run / Stop remote control.
HC_SW Open/Close - Cooling / heating remote contact.
on_ctrl Off, On Cool, On Heat, On Auto - Currentcontrolmode.
SETP_SW Open/Close - Remote setpoint contact.
LIM_SW1 Open/Close - Contact 1 for absorption remote limitation.
LIM_SW2 Open/Close - Contact 2 for absorption remote limitation.
FLOW_SW Open/Close - Contactdetectingwaterow/externalsafetyloop.
leak_1_v nn.n Volt Valuereadbyleakagedetector1.
leak_2_v nn.n Volt Valuereadbyleakagedetector2.
DSHTR_SW Open/Close - Contactforthedesuperheateravailabletotheuser.
OUTPUTS menu
Name Format Units Description
CP_A1 On/Off - Compressor A1 output.
CP_A2 On/Off - Compressor A2 output.
CP_A3 On/Off - Compressor A3 output.
fan_a1 0-2 - Fan A1 output.
fan_a2 0-2 - Fan A2 output.
exv_a 0-100 % Cooling circuit A EXV position.
HD_POS_A 0-100 % PositionofvariableowratefanregulatorA.
RV_A On/Off - CyclereversalvalvestatusofcoolingcircuitA.
CP_B1 On/Off - Compressor B1 output.
CP_B2 On/Off - Compressor B2 output.
fan_b1 0-2 - Fan B1 output.
exv_a 0-100 % Cooling circuit B EXV position.
HD_POS_B 0-100 % PositionofvariableowratefanregulatorB.
RV_B On/Off - CyclereversalvalvestatusofcoolingcircuitB.
C_HEATER On/Off - Statusofheatexchangerheaterandofcoillowerside.
BOILER On/Off - Heat generator output.
EHS_STEP 0-4 - Additionalelectricheatersteps
ALARM On/Off - Alarmrelay.
RUNNING On/Off - UnitrelayON.
