2.3 DIMENSIONS AND WEIGHT
NXC 017-021
NXC 017 021
Netweight kg 189 208
NXC 026 NXH 026 NXC 033 NXH 033 NXC 040 NXH 040
Netweight kg 255 280 280 295 291 305
1136
1579
559
584
760
1790
824 1002
995
170170 460
2.4 HANDLING AND UNPACKING
 You are hereby reminded that by using a forklift/pallet
jack
 the use of a hoist or crane is still necessary
 to be able to move RIELLO NXC/NXH and position it
 neartheenvisagedinstallationarea.
 The device must always be handled and moved in an
upright position.
 Usealiftingbarinordertopreventthepressureexerted
bythestrapsfromdamagingtheunit.
 Donottiltthedevicebymorethan15°.
Thedeviceisheavieronthecompressorside(wheretheelec-
trical
connectionsarepresent).
Theunpackingoperationsaredescribedbelow:
• remove the clear bag
• removethecardboardcoversA
• removethepolystyreneprotectionB(forNXC017-021mo-
dels
only)placedontheunitcover.
Afterunpacking,beforemovingtheproductintheselectedposi-
tion,
itisnecessarytoremovethedocumentenvelopeplacedin-
sidetheunitandthescrewsfasteningthemachinetothepallet.
B
A
A
A
A
NXC 017-021
NXC 026-040
NXH 026-040
NXC 026-040
NXH 026-040
