Riello NXHM - Page 48

110
ENGLISH
Order
number
Code State Default Min. Max.
Setting
interval
Unit
7.6 T4_AHS_ON The ambient temperature for starting the additional heating source -5 -15 30 1 °C
7.7 IBH_LOCATE IBH/AHS installation location PIPE LOOP=0; BUFFER TANK=1 0 0 0 0 °C
7.8 P_IBH1 Power input of IBH1 0 0 20 0.5 kW
7.9 P_IBH2 Power input of IBH2 0 0 20 0.5 kW
7.10 P_TBH Power input of TBH 2 0 20 0.5 kW
8.1 T1S_H.A_H
The target outlet water temperature for space heating when in holiday
away mode
25 20 25 1 °C
8.2 T5S_H.A_DHW
The target outlet water temperature for domestic hot water heating
when in holiday away mode
25 20 25 1 °C
12.1
PREHEATING FOR FLOOR
T1S t_FIRSTFH
7KHVHWWLQJWHPSHUDWXUHRIRXWOHWZDWHUGXULQJ¿UVWSUHKHDWLQJIRUÀRRU 25 25 35 1 °C
12.3 t_FIRSTFH 7KHWLPHODVWIRUSUHKHDWLQJÀRRU 72 48 96 12 hour
12.4 t_DRYUP 7KHGD\IRUZDUPLQJXSGXULQJÀRRUGU\LQJXS 8 4 15 1 day
12.5 t_HIGHPEAK The continue days in high temperature during foor drying up 5 3 7 1 day
12.6 t_DRYD 7KHGD\RIGURSSLQJWHPSHUDWXUHGXULQJÀRRUGU\LQJXS 5 4 15 1 day
12.7 T_DRYPEAK 7KHWDUJHWSHDNWHPSHUDWXUHRIZDWHUÀRZGXULQJIRRUGU\LQJXS 45 30 55 1 °C
12.8 START TIME 7KHVWDUWWLPHRIÀRRUGU\LQJXS
Hour: the
present time
(not on the
hour +1, on
the hour +2)
Minute 00
0:00 23:30 1/30 h/min
12.9 START DATE 7KHVWDUWGDWHRIÀRRUGU\LQJXS
the present
date
1/1/2000
31/12/2099 1/1/2001 d/m/y
13.1
AUTO RESTART COOL/
HEAT MODE
Enable or disable the auto restart cooling/heating mode:
0=NON,1=YES
1011/
13.2
AUTO RESTART DHW
MODE
Enable or disable the auto restart DHW mode: 0=NON,1=YES 1 0 1 1 /
14.1 POWER INPUT LIMITATION The type of power input limitation: 0=NON, 1~8=TYPE 1~8 0 0 8 1 /
15.1 M1 M2
'H¿QHWKHIXQFWLRQRIWKH00VZLWFK 5(027(212)) 7%+
ON/OFF, 2= AHS ON/OFF
0021/
15.2 SMART GRID
Enable or disable the SMART GRID: 0=NON,1=YES 0 0 1 1 /
15.3 Tw2
Enable or disable the T1b(Tw 2): 0=NON,1=YES 0 0 1 1 /
15.4 Tbt1
Enable or disable the Tbt1: 0=NON,1=YES 0 0 1 1 /
15.5 Tbt2
Enable or disable the Tbt2: 0=NON,1=YES 0 0 1 1 /
15.6 Ta
Enable or disable the Ta: 0=NON,1=YES 0 0 1 1 /
15.7 Ta-adj
The corrected value of Ta on wired controller -2 -10 10 1 °C
15.8 SOLAR INPUT
Choose the SOLAR INPUT: 0=NON, 1=CN18Tsolar, 2=CN11SL1SL2 0 0 2 1 /
15.9 F-PIPE LENGTH
Choose the total length of the liquid pipe (F-PIPE LENGTH): 0=F-PIPE
LENGTH <10m,1=F-PIPE LENGTH  10m
0011/
15.10 RT/Ta_PCB Enable or disable the RT/Ta_PCB: 0=NON,1=YES 0 0 1 1 /
15.11 PUMP_I SILENT MODE Enable or disable PUMP_I SILENT MODE 0=NON, 1=YES 0 0 1 1 /
15.12 DFT1/DFT2 DFT1/DFT2 port function. 0 = DEFROST, 1 = ALARM
0011/
16.1 PER_START Start-up percentage of multiple units 10 10 100 10 %
16.2 TIME_ADJUST Adjustment time of adding and subtracting units 5 1 60 1 min
16.3 ADDRESS RESET Reset the address code of the unit FF 0 15 1 /
17.1 HMI SET Choose the HMI: 0=MASTER, 1=SLAVE 0 0 1 1 /
17.2 HMI ADDRESS FOR BMS Set the HMI address code for BMS 1 1 16 1 /
17.3 STOP BIT
HMI stop bit 1121/
NOTE
')7')7$/$50IXQFWLRQFDQEe valid only with IDU software version higher than V99.
