• Soundproofing
The sound attenuating shroud significantly reduces the noise
generated by the burner (- 8/12 dBA).
The casing is in steel and sound-damping material and fully en-
closes the burner.
The casing is wheel-mounted so that it can be easily removed for
burner inspection.
• Complete closure of the air gate valve during pauses in
burner operation
Serves to minimize thermal dispersion caused by the stack
draught sucking air from the fan's suction opening.
This is achieved by hydraulic cylinder M, which closes the fan
gate valve completely when the burner shuts down.
mm A B C
H
kg
MIN MAX
D1 770 650 690 482 1090 52
Burner Code
PRESS GW 3000853
PRESS 1G 3000854
PRESS 2G 3000855
PRESS 3G 3000856
