Riello PRESS 2G - 4 Technical Description of the Burner; Burner Designation

7
20140894
GB
Technical description of the burner
4.1 Burner designation
4 Technical description of the burner
Series
:
PRESS
Operation : GV or G24 One stage
GW or 1-2-3-4G Two stage
Emission : ... Class 1 EN267
Head : TC Standard head
TL Extended head
Flame control system : FS1 Standard (1 stop every 24 h)
FS2 Continuous working (1 stop every 72 h)
Electrical supply of the system : 1/230/50 1/230V/50Hz
1/210/60 1/210V/60Hz
1/220/60 1/220V/60Hz
1/200/50-60 1/200V/50-60Hz
3/230-400/50 3/230V/50Hz-3N/400V/50Hz
3/210/60 3/210V/60Hz
3/220-380/60 3/220V/60Hz-3N/380V/60Hz
3/200/50-60 3/200V/50-60Hz
Auxiliary voltage : 230/50 230V/50Hz
120/60 120V/60Hz
220/60 220V/60Hz
200/50-60 200V/50-60Hz
PRESS 1G TC FS1 1/200/50-60 200/50-60
